PetFelt Etched Panel
PetFelt Etched Panel
Etched Panels offer a quick, cost-effective acoustic solution for walls and ceilings, made from the same high-quality, lightweight, recycled material as our PetFelt range. Their customizable etched designs provide excellent sound absorption while allowing you to introduce creative patterns and visual movement to any space.
Datasheet - Product Datasheet
Materials - 9, 12 & 24mm
Colours - 60+ variants
Designs: 48+ Variants
Get a Quote
Technical Data
Composition:
Recycled PET Fibre - Robust, light, no irritation, eco-friendly, washable, fade-resistant, fireproof
Dimensions:
2400 x 1200 x 9mm @ 2000gsm
2400 x 1200 x 12mm @ 2400gsm
2400 x 1200 x 24mm @ 3800gsm
(oversized available with MOQ)
Sustainability:
Contains a minimum of 75% recycled polyester fibre (Post-consumer, from PET bottle-flake), ensuring comparatively low embodied energy. Off-cuts and manufacturing waste are reused or recycled wherever possible. Uncontaminated panels can be recycled.
Installation:
May be bonded using a suitable wall or ceiling adhesive, fixed with screw, pinnails or standard picture hanging products. Can also be suspended with optional suspension cable kits. Full instructions and guidelines for fixing and placement are included in all orders.
Designs:
Our range of 48 Etched Patterns offers a diverse selection of styles, from modern linear slats to bold geometric motifs, designed to add architectural depth and visual movement to any space. These designs create a three-dimensional texture by etching physical grooves into the panels, interacting with room lighting to elevate the interior aesthetic. Whether you select a standard pattern or require a bespoke custom design, these visual enhancements provide a premium, tactile finish without compromising the panel's high-performance sound absorption.
NRC:
9mm = 0.40 | + AirGap (50mm) = 0.80
12mm = 0.40
24mm = 0.75 | + (25mm) = 0.85 | + (50mm) = 0.90
NRC = Noise reduction coefficient. A measure of a panel's overall sound reduction/absorption, ranging from 0=zero to 1=100% absorption
Fire Rating:
EN 13501-1:2018 - Class B-s1/2,d0
Colours & Samples
Resources
-
-
-
-
Specifying this product? > Copy the NBS clause below directly into your project documents. For custom cuts or prints, please contact info@gbacoustics.co.uk.
Manufacturer: GB Acoustics Ltd (www.gbacoustics.co.uk / 07488 446 696)
Product Reference: GB PetFelt Acoustic Etched Wall Panel
Material: 100% PET Polyester fiber (minimum 75% recycled plastic bottle content)
Thickness: [Select: 9mm / 12mm / 24mm]
Fire Performance (EN 13501-1:2018): [Select based on thickness: 9mm/12mm = Class B - s2, d0 | 24mm = Class B - s1, d0]
Acoustic Performance: Up to Class A sound absorption (system dependent)
Design / Pattern: [Insert pattern choice from GB Acoustics 48+ Range, or insert 'Custom design']
Colour / Finish: [Insert colour choice from GB Acoustics 60+ Colour Range, or insert 'Custom Print']
Dimensions (H x W): [Insert Dimensions, e.g., 2400mm x 1200mm / Custom cut]
Installation: Mechanically fixed or adhered directly to the substrate using manufacturer-approved grab adhesive. Ensure substrate is clean, dry, and dust-free prior to application.
Frequently Asked Questions
About Acoustic Wall Panels
-
A: Yes. While our standard sheets come in 2440mm x 1220mm, PetFelt is a versatile material that can be directly produced or CNC cut to virtually any bespoke shape, logo, or geometric design. Because the material is solid colour throughout (not a veneer), the cut edges are clean and do not require edging or framing.
-
PetFelt panels are lightweight and can be installed easily using a high-grab contact adhesive (such as our TensorGrip spray) or off-the-shelf construction adhesive. for a adhesive-free installation, they can also be mechanically fixed using screws, invisible fixings, pin-nails or a Z-clip system. The material is robust enough to pin into, making it perfect for office noticeboards.
-
A: Our 24mm panels achieve an NRC (Noise Reduction Coefficient) of 0.75 when direct-fixed to a wall. If installed with a 50mm air gap behind the panel, this performance increases to NRC 0.90, absorbing 90% of the sound energy that hits them.
-
A: No, the pound-for-pound acoustic properties remain consistent across our range. Our PetFelt Printed and Etched panels maintain the same porous structure required for sound absorption, allowing you to treat your acoustics without compromising on interior design or branding.
-
A: Superior performance and longevity. PetFelt is significantly denser than traditional acoustic foam, offering better sound absorption at the same thickness, particularly for speech frequencies. Unlike foam, which can crumble, discolor, and degrade over time, PetFelt is impact-resistant, rigid, and color-fast. It is also the sustainable choice; made from 65% recycled post-consumer plastic bottles, it contains no chemical binders and is fully recyclable.
-
A: Safety is our priority. Our PetFelt material is tested to EN13501-1 Class B-s1/2,d0. This makes them suitable for use in the majority of commercial, educational, and public environments where fire safety compliance is mandatory. They are self-extinguishing and do not produce toxic smoke or flaming droplets.
